MIL-PRF-39016/30F
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA: 1/
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
current life test
V rms
V rms (60 Hz)
Sea level
(60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
125
Between case, frame, or enclosure and coils.
500
500
All
Between all contacts and coils.
500
500
terminals
Between open contacts in the energized and
to case
de-energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
500
500
DIODE CHARACTERISTICS:
Coil transient suppression: Applicable.
Diode block integrity (perform this test after coil transient suppression test in all inspection tables of MIL-PR-
39016): With applicable voltage applied to the relay coil circuit in the reverse direction, monitor leakage current
with dc microammeter, oscilloscope, or qualifying activity approved test equipment. Leakage current shall not
exceed the specified value.
Block integrity maximum leakage current: 1µA at 50 V dc.
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc minimum at 10 microamperes (µA). (This test may be performed in-process or as
final assembly).
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073, or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
1/ Dielectric withstanding voltage and insulation resistance are not applicable between coils and case or from coil
to coil on figure 1 relays.
