MIL-PRF-83536/2B
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.055
1.40
.156
3.96
.470
11.94
.002
0.05
.060
1.52
.158
4.01
.640
16.26
.003
0.08
.065
1.65
.170
4.32
.690
17.53
.005
0.13
.070
1.78
.200
5.08
.704
17.88
.010
0.25
.075
1.90
.210
5.33
.810
20.57
.015
0.38
.080
2.03
.225
5.72
.850
21.59
.016
0.41
.095
2.41
.230
5.84
.913
23.19
.020
0.51
.110
2.79
.261
6.63
1.05
26.7
.025
0.64
.125
3.18
.292
7.42
1.062
26.97
.03
0.76
.133
3.38
.312
7.92
1.070
27.18
.031
0.79
.140
3.56
.320
8.13
1.078
27.38
.035
0.89
.141
3.58
.410
10.41
1.280
32.51
.040
1.02
.150
3.81
.450
11.43
1.422
36.12
.050
1.27
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
Unless otherwise specified, tolerance is ± .010 (0.25mm).
3.
4.
There shall be affixed to the relay a suitable legible circuit diagram that identifies each terminal location specified.
5.
These relays are polarized monostable.
6.
This relay shall not operate or be damaged by reverse polarity.
7.
Permanent magnet drive consists of a permanent magnet with its flux path switched and combined with the electro-magnet
flux.
8.
Applicable to horizontal flange mount only. The circuit diagram, manufacturer's PIN, and the military PIN shall be marked on
the near side. The remaining portion of the nameplate data shall be marked on the far side.
9.
Applicable to horizontal flange mount only. Relays shall be marked with the manufacturer's name or CAGE code and the
date code. Marking shall be with the bottom of the print adjacent to the near side.
10.
Socket pin terminals shall provide the operational, environmental, and interface characteristics to provide a reliable
interconnect to gold-plated contacts. Terminals, track mount B polarizing pin and ground pin, shall be gold plated. One
system for gold plating that may be used is ASTM B488, type 3, class 1.25 with a nickel underplate of 50 to 150 microinches
thick. The gold plating system shall enable the product to meet the performance requirements of this specification and shall
be approved by the qualifying activity.
11.
Gasket shall provide a reliable seal between the relay and mating socket that will meet the environmental, operational, and
interface requirements of the relay with the mating socket. The gasket shall have shore hardness 15 to 35, thickness .050
±.005. Gasket material according to AMS 3332 has been considered acceptable. Silicone rubber gasket is not supplied
with track mount A relays.
12.
Back EMF (transient voltage): 42 V dc maximum.
13.
JANTX or equivalent screened semiconductors or hybrid devices shall be used for internal coil suppression. Relays using
suppression devices shall continue to operate should the suppression circuits be in a failure mode. Diodes shall have a
peak inverse voltage of 600 V dc minimum.
14.
Track mount B is covered by Deutsch Relays, Inc., patent number 4,201,437.
15.
Represents minimum travel required to engage locking cutout on mating socket module.
16.
Track mount shall be corrosion resistant. One way of ensuring corrosion resistance is to nickel plate stainless steel 303 with
100 microinches minimum thickness. The finish on the top of the knob shall be lusterless black number 37038 in
accordance with FED-STD-595 except that the slot shall be white marking color, number 27886 in accordance with FED-
STD-595. The post shall be polyamide-imide in accordance with McDonnell Douglas Drawing. ST5M1454 (Deutsch Relays,
Inc. Patent number 4,201,437).
Direction of 29° rotation to engage locking cutout on mating socket module.
17.
18.
Measure from surface of header.
19.
Track mount B relay external materials and finishes shall be in accordance with McDonnell Douglas Drawing. ST5M1454
(Deutsch Relays, Inc. Patent number 4,201,437) and applicable specifications.
20.
The rotation of the knob mechanism shall be restricted such that the latching pins cannot be placed on the side opposite the
McDonnell Douglas ST5M1457 bracket cutouts.
21.
Indicated terminal shall be identified with a contrasting bead.
22.
Plane of critical motion for vibration and shock is Y-axis.
23.
Gasket shall provide a reliable seal between the relay and mating socket that will meet the environmental, operational, and
interface requirements of the relay with the mating socket. The gasket shall have shore hardness 30 to 45. Gasket material
according to AMS 3332 has been considered acceptable.
FIGURE 1. Dimensions and configurations Continued.
7
