MIL-PRF-83536/17A
mm
Inches
mm
Inches
mm
Inches
.001
0.03
.172
4.37
.937
23.80
.002
0.05
.200
5.08
1.010
25.65
.005
0.13
.218
5.54
1.025
26.04
.040
1.02
.270
6.86
1.062
26.97
.050
1.27
.310
7.87
1.396
35.46
.062
1.57
.312
7.92
1.406
35.71
.150
3.81
.625
15.88
1.446
36.73
.156
3.96
.810
20.57
1.718
43.64
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
3.
Unless otherwise specified, tolerance is ±.010 (0.25 mm).
4.
There shall be affixed to the relay a suitable legible circuit diagram that identifies each
terminal location specified.
5.
These relays are polarized monostable.
6.
Permanent magnet drive consists of a permanent magnet with its flux path
switched and combined with the electromagnet flux.
7.
Applicable to horizontal flange mount only. The circuit diagram, manufacturer's
PIN, and the military PIN shall be marked on the near side. The remaining
portion of the nameplate data shall be marked on the far side.
8. Applicable to horizontal flange mount only. Relays shall be marked with the manufacturer's
name or CAGE code and date code. Marking shall be with the bottom of the print adjacent to
the near side.
9.
Socket pin terminals shall be gold-plated in accordance with MIL-G-45204, type II,
class I. The nickel underplating shall be 50 to 150 microinches thick.
10. Silicone rubber gasket, AMS 3332, shore hardness 15 to 35, thickness .050 ±.005
(1.27 ±0.13 mm).
11. Indicated terminals shall be identified by contrasting beads.
12. For coil pin orientation, see figure 1.
13. Plane of critical motion for vibration and shock is Y-axis.
FIGURE 1. Dimensions and configurations - Continued.
