MIL-PRF-83536/12C
Inches
mm
Inches
mm
Inches
mm
.000
0.00
.156
3.96
.500
12.70
.001
0.03
.172
4.37
.525
13.34
.002
0.05
.200
5.08
.562
14.27
.005
0.13
.260
6.60
1.025
26.04
.020
0.51
.270
6.86
1.062
26.98
.030
0.76
.281
7.14
1.396
35.46
.040
1.02
.300
7.62
1.406
35.71
.062
1.57
.310
7.87
1.446
36.73
.100
2.54
.312
7.92
1.718
43.64
.150
3.81
.485
12.32
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .010 (0.25 mm).
4. There shall be affixed to the relay a suitable legible circuit diagram that identifies each terminal location
specified.
5. These relays are polarized bistable.
6. This relay shall not be damaged by reverse polarity.
7. Applicable to horizontal flange mount only. The circuit diagram, manufacturer's PIN, and the military PIN shall
be marked on the near side. The remaining portion of the nameplate date shall be marked on the far side.
8. Applicable to horizontal flange mount only. Relays shall be marked with the manufacturer's name or CAGE
code and date code. Marking shall be with the bottom of the print adjacent to the near side.
9. Socket pin terminals shall provide the operational, environmental, and interface characteristics to provide a
reliable interconnect to gold-plated contacts. Terminals, except the polarizing pin, shall be gold plated. One
system for gold plating that may be used is ASTM B488, type 3, class 1.25 with a nickel underplate of 50 to
150 microinches thick. The gold plating system shall enable the product to meet the performance
requirements of this specification and shall be approved by the qualifying activity.
10 Gasket shall provide a reliable seal between the relay and mating socket that will meet the environmental,
operational, and interface requirements of the relay with the mating socket. The gasket shall have shore
hardness 15 to 35, thickness .050 .005 (1.27 ± 0.13 mm). Gasket material according to SAE-AMS3332 has
been considered acceptable.
11. Relay is magnetically latched in both positions.
12. All hooks shall be tin finished..
13. Relays shall have a (+) sign placed on the circuit diagram as shown.
14. Coil symbol optional in accordance with MIL-STD-1285.
15. Indicated terminals shall be identified by a contrasting bead.
16. Direction of hook openings is optional.
17. Plane of critical motion for vibration and shock is Y-axis.
FIGURE 1. Dimensions and configurations - Continued.
5
