MIL-PRF-83536/12C
Socket pin terminals:
Pull force:
For .031 diameter terminals: 3 pounds 0.3 pound (applicable to track mount).
For .062 diameter terminals: 10 pounds 1.0 pound.
Bend: Applicable.
Twist: Applicable to coil terminals Y1 and Y2 only.
Terminal solderability: Applicable to solder hook terminals only.
Seal: Hermetic.
Marking: Applicable.
Part or Identifying Number (PIN): M83536/12 (dash number from table III and suffix letter designating failure rate
level).
Qualification inspection:
Qualification inspection and sample size: See table IV.
TABLE IV. Qualification inspection and sample size. 1/
Single submission
Group submission
18 units plus 1 open unit
M83536/12-008
18 units plus 1 open unit
for level L at C = 0 2/
for level L at C = 0 2/
33 units plus 1 open unit
M83536/12-008
33 units plus 1 open unit
for level M at C = 0 2/
for level M at C = 0 2/
Qualification inspection
M83536/12-008
Qualification inspection as
as applicable
applicable
M83536/12-009
2 units, qualification
inspection table,
group II, shock, vibration,
acceleration, terminal
strength, and seal.
M83536/12-002
2 units, qualification
inspection
M83536/12-006
table , group II
M83536/12-012
1/ For retention of qualification or extension of qualification to lower failure rate
levels, all life test data accumulated on MIL-PRF-83536/13 may be used in
addition to MIL-PRF-83536/12 data. Prior to performance of retention of
qualification testing, the relay manufacturer shall preselect the sampling plan.
2/ The number of units required for qualification testing shall be increased as
required in group V, table II of MIL-PRF-83536, if the contractor elects to test
the number of units permitting one or more failures. Prior to performance of
qualification testing, the relay manufacturer shall preselect the sampling plan.
