MIL-PRF-6106/19G
TABLE IV. Time current relay characteristics at 25C. 1/ 2/ 3/
Amperes
Duration
30
1 hour
50
5.0 seconds
100
1.2 seconds
250
0.2 second
350
0.1 second
1/ Applicable to dash numbers-005 through -024.
2/ CAUTION: Compare with time current characteristics of the
associated circuit protective device.
3/ Dash nos. -005 through -024. Relays shall sustain five
applications (make and carry only) of power at each of five
different current levels for the time durations in table IV.
Separate relays shall be tested at 28 V dc and 115 V ac,
400 Hz. Cooling time between successive applications
shall be 30 minutes. The test shall be performed on both
normally open and normally closed contacts of each relay.
There shall be no failures or evidence of welding or sticking
and relays shall pass contact voltage drop at conclusion.
Cross reference for Government logistical support. See table V.
TABLE V. Cross reference for Government logistical support.
PIN M6106/19-
Support with PIN
PIN M6106/19-
Support with PIN
M6106/19-
M6106/19
003
003
015
020
004
004
016
021
005
020
017
022
006
021
018
023
007
022
019
024
008
023
020
020
009
024
021
021
010
020
022
022
011
021
023
023
012
022
024
024
013
023
025
025
014
024
Supersession data: See table VI.
TABLE VI. Supersession data.
Superseded
PIN
New PIN
M6106/19-
M6106/19-
001
011
002
012
10
