MIL-PRF-39016/44E
Electrical data:
Insulation resistance: 1,000 megohms minimum.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and between all
contacts in the energized and deenergized positions -
1,000
Between case, frame, or enclosure and coil(s) - - - - - - -
500
350
Between all contacts and coil(s) - - - - - - - - - - - - - - - - -
1,000
All terminals
Between open contacts in the energized and
to case
deenergized positions - - - - - - - - - - - - - - - - - - - - -
500
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
1,000
Environmental data:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204, test condition D (except 10 to 2,500 Hz). Contact chatter
shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open
contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts (applicable
for qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition A (50 g). Contact chatter shall not exceed
10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
Physical:
Dimensions and configurations: See figure 1.
Weight: 13 grams (0.46 ounce) maximum.
Terminals: See figure 1 and table I.
Terminal strength: 3 ±0.3 pounds pull.
Solderability: Applicable.
Terminal twist test: Applicable to wire leads.
