MIL-PRF-39016/28F
COIL DATA: See table I.
Operate time: 1.5 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA:
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
V rms (60
current life
V rms (60 Hz)
Hz)
test Sea level
V rms (60 Hz)
Between case, frame, or enclosure and all
contacts in the energized and de-energized
500
500
125
positions.
All terminals
Between case, frame, or enclosure and coils.
500
500
to case
Between all contacts and coils.
500
500
Between open contacts in the energized and de-
energized positions.
500
375
Between contact poles.
N/A
N/A
Between coils of dual coil relays.
500
500
DIODE CHARACTERISTICS: 1/
Coil transient suppression: Applicable.
Diode block integrity (perform this test after coil transient suppression test in all inspection tables of MIL-PRF-
39016): With applicable voltage applied to the relay coil circuit in the reverse direction, monitor leakage current
with dc microammeter, oscilloscope, or qualifying activity approved test equipment. Leakage current shall not
exceed the specified value.
Block integrity maximum leakage current: 1µA at 50 V dc.
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc minimum at 10 microamperes (µA). (This test may be performed in-process or as
final assembly).
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073, or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
1/ WARNING: Reverse polarity on coil terminals will destroy diode.
4
