MIL-PRF-39016/19H
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: 4.0 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and
case at high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
V rms (60 Hz)
V rms (60 Hz)
current life
test Sea level
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
125
Between case, frame, or enclosure and coil.
500
500
All terminals
Between all contacts and coils.
500
500
to case
Between open contacts in the energized and
de-energized positions.
500
375
Between contact poles in the energized and
500
500
de-energized positions.
Between coils of dual coil relays.
N/A
N/A
DIODE CHARACTERISTICS
Coil transient suppression: Applicable.
Diode block integrity (perform this test after coil transient suppression test in all inspection tables of MIL-
PRF-39016): With applicable voltage applied to the relay coil circuit in the reverse direction, monitor
leakage current with dc microammeter, oscilloscope, or qualifying activity approved test equipment.
Leakage current shall not exceed the specified value.
Block integrity maximum leakage current: 1µA at 50 V dc.
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc minimum at 10 microamperes (µA). (This test may be performed in-
process or as final assembly).
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in
accordance with MIL-STD-750, method 2073 or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall
not exceed 10 microseconds maximum for closed contacts, and 1 microsecond maximum closure for
open contacts.
