MIL-PRF-39016/17H
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
18 units plus 1 open unit for level L
M39016/17-036
18 units plus 1 open unit for
at C = 0 2/
level L at C = 0 2/
33 units plus 1 open unit for
33 units plus 1 open unit for level M
at C = 0 2/
level M at C = 0 2/
Qualification inspection as
Qualification inspection as
applicable.
applicable.
M39016/17-031
2 units each PIN
M39016/17-032
Qualification inspection,
table, Q2.
M39016/17-033
M39016/17-034
M39016/17-035
M39016/17-048
1 unit terminal strength and
solderability
1/ For retention of qualification or extension of qualification to lower failure rate levels, all life
test data accumulated on MIL-PRF-39016/18, /19, /41, /42, and /43, may be used in
addition to MIL-PRF-39016/17 data. Prior to performance of qualification or extension of
qualification testing, the relay manufacturer shall preselect the sampling plan.
2/ The number of units required for qualification testing shall be increased as required in Q5,
MIL-PRF-39016, if the relay manufacturer elects to test the number of units permitting one
or more failures. Prior to performance of qualification inspection testing the relay
manufacturer shall preselect the sampling plan.
Qualification inspection (reduced testing) (sample size - 2 size each coil voltage and 1 unsealed unit).
See table III.
If the relays produced for MIL-PRF-39016/17 are similar in construction and design except for the suppresser
and steering diodes and coil assembly, as applicable, to the relays produced for MIL-PRF-39016/18, /19, /41,
/42, and /43, then reduced testing for qualification of MIL-PRF-39016/17 relays may be performed concurrent
with or subsequent to successful qualification of MIL-PRF-39016/18, /19, /41, /42, and /43 relays. For reduced
testing, see table III.
TABLE III. Qualification inspection (reduced testing).
Examination or test
2 units each coil voltage
Q1 of qualification inspection table
1 unsealed sample unit for internal examination.
Initial qualification of relays supplied with spacer mounting pads (-37 through -042 and -049 through -054) shall be
tested as specified below:
Perform the following tests as specified in the qualification inspection table of MIL-PRF-39016, in the order
shown below:
