MIL-PRF-39016/17H
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: 1.5 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
V rms (60 Hz)
V rms (60 Hz)
current life
test Sea level
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
125
Between case, frame, or enclosure and coils.
500
500
All terminals
Between all contacts and coils.
500
500
to case
Between open contacts in the energized and
de-energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
N/A
N/A
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Applicable to qualification and group C testing only.
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall not exceed
10 microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
Salt atmosphere (corrosion): In accordance with method MIL-STD-750, 1041.
4
