MIL-PRF-39016/12G
Contact stabilization time: 2.5 milliseconds maximum (applicable to failure rate levels "M", "P", and "R").
Overload (high level only): Two times rated current. Not applicable to ac load ratings.
Neutral screen: Applicable.
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA: 1/
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
V rms (60
current life
V rms (60 Hz)
Hz)
test Sea level
V rms (60 Hz)
Between case, frame, or enclosure and all
contacts in the energized and de-energized
500
500
125
positions.
All terminals
Between case, frame, or enclosure and coils.
500
500
to case
Between all contacts and coils.
500
500
Between open contacts in the energized and de-
energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
500
500
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds
maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Applicable to qualification and group C testing only.
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall not exceed
10 microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
1/ Dielectric withstanding voltage and insulation resistance are not applicable between coil and case or from coil to
coil on figure 1 relays and circuit diagram 1 relays on figure 3.
5
