MIL-DTL-83729/6C
REQUIREMENTS:
Contact data:
Single pole, double throw, break before make.
Polarity: With positive dc voltage on pin 3 and negative voltage on pin 4, pins 6 and 7 are closed.
Voltage and current: Dry circuit to 100 volts, 2 milliamperes dc resistive (maximum intermittent rating) 10 volts, 1
milliampere continuous dc resistive rating.
Coil data:
Voltage rated: 6.3 volts ± 0.6 volts rms.
Resistance, dc: 155 ohms ± 10 percent at 25°C.
Impedance: See table I.
Frequency range: See table I.
Waveform characteristics (6.3 volts at 25°C ± 5°C):
Dwell time: See table I.
Dissymmetry: 15° maximum.
Transfer time: See table I.
Phase angle: See table I.
Noise level: See table I.
Environmental conditions:
Dielectric withstanding voltage: See table I.
Insulation resistance: Between terminals and case 1,000 megohms at 100 volts dc.
Vibration III: Nonoperating, MIL-STD-202, method 204, condition A, except 5 g's maximum.
Shock: Nonoperating, 100 g's as specified in MIL-STD-202, method 213, test condition I.
Temperature range: -65°C to +125°C.
Life: 5,000 hours minimum at dry circuit, 25°C ± 5°C.
Mechanical:
Weight: .09 pound, maximum.
Dimensions: See figure 1.
Enclosure: Hermetically sealed, chopper mates with JAN TS102P01 socket with a TS102U02 tube shield to
secure in the socket.
Terminal strength: 2.5 pounds.
Mounting position: Any.
Part or Identifying Number (PIN): M83729/6- (dash number from table I).
TABLE I. Dash number and characteristics.
Dash
Imped-
Frequency
Dwell
Transfer
Phase
Noise
Dielectric
number
ance
range
time
time
angle
level
Withstanding
voltage
001
250
400 ± 20 Hz
130°
15°
65°
200 microvolts rms
200 V rms at 60 Hz
± 20% at
to
min
± 15°
above system noise
or 280 V dc
25°C
165°
level with 1.0 meg-
ohm load resistor.
002
175
60 ± 5%
150°
3°
20°
50 microvolts rms
200 V rms at 60 Hz
± 20% at
min
min
± 5°
above system noise
or 280 V dc
25°C
level with 1.0 meg-
ohm load resistor.
2
