MIL-DTL-83729/1E
TABLE I. Dash number and characteristics.
Coil
Dielectric
Dash
Voltage
Resistance
Impedance
Frequency
Dwell
Transfer
Phase
Withstanding
Number
rated
dc
range
time
time
angle
voltage
6.3 volts,
85 ohms
115 ohms
0 to
140°
2.5° min
65°
145 Vrms,
001
400 Hz at
± 10%
± 20%
1,000 Hz
to
400 Hz at
± 15°
400 Hz or
25°C only
185°
25°C
200 Vdc for
60 seconds
6.3 volts,
310 ohms
330 ohms
0 to
155°
2.5° min
25°
145 Vrms,
002
60 Hz at
± 10%
± 20%
250 Hz
to
60 Hz at
± 10°
60 Hz or
25°C only
185°
25°C
200 Vdc for
60 seconds
