INCH-POUND
MIL-DTL-19648E
3 February 2003
SUPERSEDING
MIL-DTL-19648D
15 February 2002
DETAIL SPECIFICATION
RELAYS, TIME DELAY, THERMAL,
GENERAL SPECIFICATION FOR
Inactive for new design after 15 February
2002. No superseding specification.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for thermal, time delay relays for use in
electrical applications. Relays covered by this specification are capable of meeting the electrical and environmental
requirements when mounted directly to the structure of aircraft, missile, spacecraft, ship, and other primary vehicles
or in ground support and shipboard equipment. Other ratings may be as specified (see 3.1).
1.2 Classification.
1.2.1 Military part number. The military part number is to consist of the letter "M," the basic number of
the specification sheet, and an assigned dash number (see 3.1) as shown in the following:
M19648
/1
-101
|
|
|
|
|
|
Specification
Specification
Dash
designator
sheet number
number
1.2.2 Levels and classes. Relays covered by this specification are to be of the following levels and
classes, as specified (see 3.1 and 6.2.1).
1.2.2.1 Shock. The shock level is to be in accordance with table I as specified (see 3.1 and 6.2.1).
TABLE I. Shock level.
Applicable test method
Level
Test condition
of MIL-STD-202
1
G
213
2
I
213
3
Hi-impact
207
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of
use in improving this document should be addressed to Defense Supply Center, Columbus, Post Office
Box 3990, Columbus, OH 43216-5000, by using the Standardization Document Improvement Proposal
(DD Form 1426) appearing at the end of this document or by letter.
AMSC N/A
FSC 5945
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
