AN3362
REVISION 7
REQUIREMENTS:
Operating cycles: 50,000 minimum.
Contact data:
Contact voltage drop:
Initial: 0.150 volt maximum.
After life: 0.175 volt maximum.
Load ratings:
See Table l.
TABLE l Rated contact load (per pole).
Type of load
Amperes
100
Resistive (DC)
75
Resistive (AC 400 Hz, 115 volts)
80
Inductive
80
Motor (DC)
Motor (AC 400 Hz, 115 volts)
65
Coil data:
Nominal coil voltage: Rated.
Maximum operating voltage: 29 volts.
Pickup voltage: 20 volts.
Hold voltage:
7 volts.
Dropout voltage:
1.5
Rated duty:
Continuous.
Coil current: 0.6 amperes
Physical data:
Weight: 1.5 pounds maximum.
Part or Identifying Number (PIN): AN3362-1
3
