AN3335
REVISION 5
Inches
mm
Inches
mm
.010
0.025
.500
1.270
.062
0.158
.563
1.428
.125
0.317
.656
1.666
.219
0.555
.844
2.143
.250
0.635
2.000
5.08
.281
0.714
2.500
6.350
.344
0.873
2.594
6.588
.438
1.111
3.016
7.659
.469
1.191
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance are ±.016 (0.040 mm).
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 50,000 minimum.
Contact voltage drop:
Initial: 0.150 volt maximum.
After life: 0.175 maximum.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Type of load
Amperes
Resistive (400Hz, 115/200 Volts
5
AC or 28 Volts DC)
Inductive (DC 28 Volts)
2
Motor (400Hz, 115/200 Volts AC
5
or 28 Volts DC)
2
