AN3320
REVISION 4
Inches
mm
Inches
mm
.016
0.406
.437
11.099
.031
0.787
.527
13.386
.040
1.016
.531
13.487
.041
1.041
.560
14.224
.062
1.574
.687
17.449
.125
3.175
.875
22.225
.205
5.207
1.390
35.506
.219
5.563
1.937
49.199
.250
6.350
2.625
66.675
.260
6.604
3.140
79.756
.375
9.525
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance are .016 (0.040 mm).
4. Terminal post holes shall be counterbored and properly filled with socket compound, or equivalent.
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 50,000 minimum.
Contact data:
Contact voltage drop: Not applicable.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Type of load
Amperes
Resistive (DC)
25
Inductive
25
Motor
25
Overload current: Not applicable.
Rupture current: Not applicable.
2
