MIL-S-12109/4
31 October 1968
MILITARY SPECIFICATION SHEET Solenoid, Electrical, Class 2 (Machine Gun),
Cal .30, 24 Volt DC, 4.5 AMP Max
The complete requirements for procuring the Solenoid described herein shall consist of this document and the issue in effect of Specification MIL-S-12109.
This specification is mandatory for use by all Departments and Agencies of the
Department of Defense.
Note: Dimensions are in inches. Unless-otherwise specified, tolerances are +.010 on decimal,
+20 on angular dimensions.
FSC-5945
