MIL-R-83726/22F
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.010 (0.25 mm) for three place decimals and
±.03 (0.8 mm) for two place decimals.
4. Spare terminals are connected internally. Do not use for external tie points or for terminals.
FIGURE 1. Dimensions and configurations - continued.
