MIL-PRF-83726/30J
Dielectric withstanding voltage: 1,000 V rms at 60 Hz at sea level, and 350 V rms at 80,000 feet
between case and pins connected together. (Terminals X1, X2 and D1, D3 must be connected
together during this test. Dielectric withstanding voltage is measured between all mutually insulated
terminals and between all terminals and case.)
ENVIRONMENTAL REQUIREMENTS:
Ambient temperature (operating or non-operating): -55C to +125C.
Vibration (sinusoidal): 30 g's, 10 Hz to 3,000 Hz.
Moisture resistance: Not applicable.
Vibration (random): 0.4 g2/Hz power spectral density, 50 Hz to 2,000 Hz in accordance with
MIL-STD-202, method 214, test condition 1G. Duration of 15 minutes each plane.
Shock (specified pulse): 100 g's, 6 ms 1 ms, ½ sine, 3 axes.
Acceleration: 15 g's in any axis.
Seal: Hermetic.
Maximum altitude rating: 80,000 feet.
PHYSICAL REQUIREMENTS:
Dimensions and configuration: See figure 1.
Mating socket: MIL-DTL-12883/40-01, MIL-DTL-12883/40-05, MIL-DTL-12883/40-07,
MIL-DTL-12883/40-11, MIL-DTL-12883/40-13, MIL-DTL-12883/40-17, MIL-DTL-12883/40-19, or
MIL-DTL-12883/40-23 in accordance with MIL-DTL-12883/40. (CAUTION: Consideration should
be given to ambient temperature and current requirements when using wire barrels size 20.)
Terminations: See figure 1.
Terminal strength: 3 pounds pull.
Weight: 2.5 ounces maximum.
Marking: See MIL-PRF-83726. In addition, relays shall be marked with the ESDS identifier as
specified in MIL-STD-1285.
Part or Identifying Number (PIN): Consists of the prefix M83726/30-, a four digit dash number (time
delay expressed in milliseconds), and a suffix letter (P for plug-in; S for solder lug) as follows:)
M
83726/30-
1001
P
Military designation
Specification sheet number
The first three digits are significant; the fourth is the number
of zeros to follow the first three digits. The time is
expressed in milliseconds and converted to seconds. (See
examples.)
Suffix letter. (Any relay numbered prior to the date of this specification shall
be considered interchangeable with same mounting type, store and issue.)
5
