MIL-PRF-83726/21G
R
1
EXT
R
R
2
Ltr
Inches
mm
Min
Max
Min
Max
A
---
.810
---
20.57
B
---
.310
---
7.87
C
.182
.192
4.62
4.88
D
.028 DIA
.033 DIA
0.71 DIA
0.84 DIA
E
.010
.020
0.25
0.51
F
---
.190
---
4.83
G
.020
.030
0.51
0.76
H
---
.410
---
10.41
J
.088
.098
2.24
2.49
K
.195 TYP
.205 TYP 4.95 TYP
5.21 TYP
L
.095 REF
.105 REF 2.41 REF
2.67 REF
M
.118 DIA
.122 DIA
3.00 DIA
3.10 DIA
N
---
1.280
---
32.51
P
1.057
1.067
26.85
27.10
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .010 (0.25 mm) for three place decimals and .03 (0.76
mm) for two place decimals.
4. Spare terminals are connected internally. Do not use for external tie points or for terminals.
FIGURE 1. Outline drawing and dimensions - Continued.
