MIL-PRF-83536/25A
Dielectric withstanding voltage 2/:
Coil to case
All other points
Sea level:
Initial:
1,000
1,250
After life:
1,000
1,000
Altitude:
At 80,000 feet:
350
350
At 300,000 feet:
500
500
Environmental characteristics:
Temperature range: -70°C to +125°C.
Maximum altitude rating: 300,000 feet.
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C except peak value shall be
50 g's for 6 to 9 ms. Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1
microsecond maximum closure for open contacts.
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, 20 g's, except frequency range shall be 10 to
2,000 Hz. Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond
maximum closure for open contacts.
Vibration (random): Applicable to qualification and group C inspection. Test in accordance with MIL-STD-202,
2
method 214, test condition IF (0.3 g /Hz, 50 to 2,000 Hz). Contact chatter shall not exceed 10 microseconds
maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Acceleration: Applicable, except 15 g's.
Physical data:
Dimensions and configurations: See figure 1.
Weight: 0.26 pound (117.94 grams).
Terminal strength:
Solder hook terminals:
Pull force: 10 pounds ±1.0 pound.
Bend: Applicable.
Twist: Not applicable.
Socket pin terminals:
Pull force: For .062 diameter terminals: 10 pounds ±1.0 pound.
Bend: Applicable.
Twist: Not applicable.
__
2/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
