MIL-PRF-83536/21B
Dielectric withstanding voltage 2/:
Coil to case
All other points
Sea level:
Initial:
1,000
1,250
After life:
750
1,000
Altitude:
At 80,000 feet:
250
250
At 300,000 feet:
500
500
Environmental characteristics:
Temperature range: -70C to +125C.
Maximum altitude rating: 300,000 feet.
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C 200 g's for 6 1 ms, except
horizontal flange mount peak g value shall be 100 g's for 6 1 ms. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, 30 g's, except frequency range shall be 70 to
3,000 Hz. Horizontal flange mount shall be 20 g's, 57 to 3,000 Hz. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): Applicable to qualification and group C inspection. Test in accordance with MIL-STD-202,
2
method 214, test condition IG (0.4 g /Hz, 50 to 2,000 Hz), for horizontal flange mount test condition IE (0.2
2
g /Hz). Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond
maximum closure for open contacts.
Acceleration: Applicable, except 15 g's.
Physical data:
Dimensions and configurations: See figure 1.
Weight: 0.062 pound (28.15 grams).
Terminal strength:
Solder hook terminals:
Pull force: 5 pounds 0.5 pound.
Bend: Not applicable.
Twist: Not applicable.
Socket pin terminals:
Pull force:
For .030 diameter terminals: 3 pounds 0.3 pound.
For .062 diameter terminals: 10 pounds 1.0 pound.
2/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
9
