MIL-PRF-83536/18C
Dielectric withstanding voltage 2/:
All others
Coil to coil
Coil to case
All other points
Sea level:
Initial:
1,000
1,250
After life:
1,000
1,000
Altitude:
At 80,000 feet:
250
350
At 300,000 feet:
500
500
Maximum leakage current: 100 microamperes rms in accordance with MIL-PRF-83536.
Environmental characteristics:
Temperature range: -70C to +125C.
Maximum altitude rating: 300,000 feet.
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C except peak value shall be
200 g's for 6 1 ms. Horizontal flange mount peak value shall be 100 g's for 6+1 ms. Contact chatter shall not
exceed 10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, test condition G, except frequency range shall be
30 g's 10 to 3,000 Hz. Horizontal flange mount shall be 20 g's, 57 to 3,000 Hz. Contact chatter shall not
exceed 10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): Applicable to qualification and group C inspection. Test in accordance with MIL-STD-202,
2
2
method 214, test condition IG (0.4 g /Hz, 50 to 2,000 Hz). Horizontal flange mount shall be at (0.2 g /Hz, 50 to
2,000 Hz). Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond
maximum closure for open contacts.
Acceleration: Applicable, except 15 g's.
Physical data:
Dimensions and configurations: See figure 1.
Weight: 0.17 pound (77.2 grams).
Terminal strength:
Solder hook terminals:
Pull force: 10 pounds 1.0 pound.
Bend: Applicable.
Twist: Not applicable.
2/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
