MIL-PRF-83536/16C
TABLE III. Dash numbers and characteristics - Continued. 1/
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10
mA resistive at 6 V dc maximum or peak ac open circuits are not recommended for subsequent use in low level
applications.
2/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed
dash number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example: 001L,
002R.
3/ CAUTION: The use of any coil voltages less than the rated coil voltage will compromise the operation of the
relay.
4/ Pickup, hold, and dropout voltages are for test purposes only and are not to be used for design criteria.
5/ When maximum ambient temperature does not exceed +85°C, the maximum coil voltage shall be 32 V dc.
6/ Dash number -034 is supplied without internal arc barriers. This relay is not rated for ac loads.
Electrical data:
Insulation resistance:
Initial: 100 megohms minimum at 500 V dc.
After life or environmental tests: 100 megohms minimum at 500 V dc (track mount). 50 megohms minimum at 500
V dc (all others).
Dielectric withstanding voltage 3/:
Track mount
All others
Coil to coil
All other points
Coil to coil
All other points
Coil to case
Coil to case
Sea level:
Initial:
1050
1500
1000
1250
After life:
1050
1250
1000
1000
Altitude:
At 80,000 feet:
350
350
250
350
At 300,000 feet:
N/A
N/A
500
500
Maximum leakage current for track mount only: 100 microamperes rms.
Environmental characteristics:
Temperature range: -70°C to +125°C.
Maximum altitude rating: 300,000 feet, (80,000 feet for track mount).
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C, 200 g's for 6 ±1 ms, except
horizontal flange mount peak g value shall be 100 g's, for 6 ±1 ms. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, 30 g's, except frequency range shall be 10 to
3,000 Hz. Horizontal flange mount shall be 20 g's, 57 to 3,000 Hz. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
3/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
13
