MIL-PRF-39016/8H
Inches
mm
Ltr
Min
Max
Min
Max
A
.275
.335
6.99
8.51
B
---
.398
---
10.11
C
.012
.016
0.30
0.41
D
.370
---
9.40
---
E
.016
.019
0.41
0.48
F
.025
.045
0.64
1.02
G
---
.370
---
9.40
H
.028
.034
0.71
0.86
J
.090
.110
2.29
2.79
K
.140
.160
3.56
4.06
L
.090
.110
2.29
2.79
M
.190
.210
4.83
5.33
N
.290
.310
7.37
7.87
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .010 (0.25 mm).
4. Spreader mounting pads shall comply with the requirements of A-A-55485, A-A-55485/5-003, or A-A-55485/5-
013.
5. Dimensions and tolerance shown for the bottom view of the spreader mounting pad are for the center-to-center
locations of the holes in the spreader mounting pad.
6. Shape optional within the envelope dimension.
7. Coil symbol optional in accordance with MIL-STD-1285.
8. Relays shall have a (+) sign placed on circuit diagram as shown.
9. All leads shall be electrically insulated from the case.
10. Circuit diagram shown on part is the terminal view.
11. Terminal numbers shown above for reference only. Numbers do not appear on relay.
FIGURE 2. Dimensions and configuration relay with spreader mounting pad attached -Continued.
4
