MIL-PRF-39016/27F
COIL DATA: See table I.
Operate time: 1.5 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA:
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
V rms (60 Hz)
current life
V rms (60 Hz)
test Sea level
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
125
Between case, frame, or enclosure and coils.
500
500
All terminals
Between all contacts and coils.
500
500
to case
Between open contacts in the energized and
de-energized positions.
500
375
Between contact poles.
N/A
N/A
Between coils of dual coil relays.
500
500
DIODE CHARACTERISTICS: 1/
Maximum transient voltage: 1 volt.
Coil transient suppression: Applicable.
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073, or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts (applicable
to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall not exceed
10 microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
1/ WARNING: Reverse polarity on coil terminals will destroy diode.
4
