TABLE I. Dash numbers and characteristics. 1/
At 25°C
Dash numbers 2/
Over temperature range
Coil voltage
Relays
Speci-
Lead
Lead
Speci-
Lead
Speci-
Coil
Speci-
Speci-
Speci-
(V dc) 3/
length
length
length
with
resis-
fied
fied
fied
fied
fied
fied
1.500
.187
.500
spreader
tance
pick-
hold
drop-
pickup
hold
drop-
±.010
min
min
mounting
ohms
up
value
out
out
value
value
4/
value
10%
pads
(volt.
value
(volt.)
(volt.)
value
(fig. 2)
(volt.
(V dc)
(volt.)
(V dc)
(V dc)
(volt.)
5/
(V dc)
(V dc)
(V dc)
Rated
Max
017
025
033
041
5.0
8.0
125
2.8
1.7
0.23
3.7
2.4
0.15
018
026
034
042
6.0
11
255
3.5
2.0
0.28
4.5
2.8
0.18
019
027
035
043
12
22
1,025
7.0
4.0
0.63
9.0
5.6
0.40
020
028
036
044
26.5
45
4,000
14.2
8.0
1.37
18
10.4
0.89
021
029
037
045
32
57
6,500
18.7
10.6
1.59
24
15
1.0
022
030
038
046
40
75
11,000
23.3
13.3
2.0
30
18.7
1.3
023
031
039
047
9.0
16
630
5.3
3.0
0.54
6.8
4.2
0.35
024
032
040
048
18
33
2,300
10.5
6.0
0.91
13.5
8.4
0.58
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10 mA
resistive at 6 V dc maximum or peak ac open circuits not recommended for subsequent use in low level
applications.
2/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed
dash number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example, 017L - - - - -
-48R.
3/ CAUTION: The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
4/ 1.500 leads are inactive for new design.
5/ Relays supplied with spreader mounting pads (-041 through -048) shall have the spreader mounting pad rigidly
attached.
