TABLE I. Dash numbers and characteristics. 1/
At 25°C
Dash numbers 2/
Coil
Over temperature
range
voltage
(V dc) 3/
Coil
Lead
Speci-
Lead
Speci-
Lead
Speci-
Relays
Speci-
Speci-
Speci-
resist-
fied
length
fied
fied
length
fied
fied
length
fied
with
ance
pick-
hold
.500
drop-
spreader
pickup
1.500
hold
.187
drop-
±.010
ohms
min
up
value
min
out
mounting
value
value
out
±10%
4/
value
(volt.)
value
pads
(volt.)
(volt.)
value
(volt.)
(V dc)
(volt.)
(fig.2)
(V dc)
(V dc)
(volt.)
Rated
Max
5/
(V dc)
(V dc)
(V dc)
013
019
025
031
5.0
5.8
63
2.8
1.7
0.23
3.7
2.4
0.15
014
020
026
032
6.0
8.0
125
3.5
2.0
0.28
4.5
2.8
0.18
015
021
027
033
9.0
12
280
5.3
3.0
0.54
6.8
4.2
0.35
016
022
028
034
12
16
500
7.0
4.0
0.63
9.0
5.6
0.40
017
023
029
035
18
24
1,130
10.5
6.0
0.91
13.5
8.4
0.58
018
024
030
036
26.5
32
2,000
14.2
8.0
1.37
18.0
10.4
0.89
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10 mA
resistive at 6 V dc maximum or peak ac open circuits not recommended for subsequent use in low level applications.
2/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed dash
number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example, 013L - - - - - -030R.
3/ CAUTION: The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
4/ 1.500 leads are inactive for new design.
5/ Relay supplied with spreader mounting pads (-031 through -036) shall have the spreader mounting pad rigidly
attached.
