TABLE I. Dash numbers and characteristics. 1/
At +25°C
Dash numbers 2/
Over temperature range
Supply
Spec.
Coil
.500
Mount-
Spec.
Spec.
Spec.
Spec.
Spec.
Coil circuit current
voltage
pick-up
resis-
min
ing
hold
dropout
pickup
hold
dropout
(mA)
(V dc) 4/
volt.
tance
leads
pads
5/ 6/
volt.
volt.
volt.
volt.
volt.
(V dc)
(ref.
3/
(V dc)
(V dc)
(V dc)
(V dc)
(V dc)
6/
only)
6/
6/
6/
6/
6/
ohms
5/
Max
Min
Rated
Max
001
007
5.0
5.6
39
132.3
96.5
2.9
1.4
0.23
4.0
2.3
0.13
002
008
6.0
8.0
78
83.9
60.3
3.5
2.0
0.32
4.9
3.2
0.18
003
009
9.0
12.0
220
47.1
33.1
5.3
3.0
0.48
7.3
4.9
0.27
004
010
12.0
16.0
390
36.1
24.9
7.1
4.0
0.65
9.8
6.5
0.36
005
011
18.0
24.0
880
24.1
16.1
10.6
6.0
0.97
14.6
9.8
0.54
006
012
26.5
32.0
1,560
19.9
12.9
14.2
8.0
1.30
19.5
13.0
0.72
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10 mA resistive at
6 V dc maximum or peak ac open circuit are not recommended for subsequent use in low level applications.
2/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed dash number.
Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example: 001L - - - - - -006R.
3/ Relays supplied with spacer pads (-007 through -012) shall have the pad rigidly attached.
4/ CAUTION: The use of any supply voltage less than the rated supply voltage will compromise the operation of the relay.
5/ Coil resistance not directly measurable at relay terminals. When rated supply voltage is applied to the supply terminals, the coil
circuit current must be within the limits shown. Measure at 25°C at rated supply voltage for 5 seconds, maximum.
6/ Set control signal voltage from 4.3 V dc to 15 V dc during electrical measurements.
