MIL-DTL-19648/1G
Supersession information: See table II.
First article inspection and sample size: See table III.
TABLE I. Relay dash numbers and applicable characteristics.
Operate time
Contact
Normal operate
Operate time
Heater
M19648/1-
seconds range
voltage 1/
arrangement
time (N.O.T.)
tolerance 3/
seconds 2/
101
6.3
NO
6
3- 8
102
6.3
NO
10
8 - 12
103
6.3
NO
20
12 - 22
104
6.3
NO
30
22 - 33
105
6.3
NO
40
33 - 45
106
6.3
NO
60
45 - 65
107
6.3
NO
80
65 - 90
108
6.3
NO
120
90 - 125
109
6.3
NO
160
125 - 180
110
6.3
NC
6
3- 8
111
6.3
NC
10
8 - 12
112
6.3
NC
20
12 - 22
113
6.3
NC
30
22 - 33
114
6.3
NC
40
33 - 45
115
6.3
NC
60
45 - 65
116
6.3
NC
80
65 - 90
117
6.3
NC
120
90 - 125
118
6.3
NC
160
125 - 180
±10% 4/
of N.O.T.
119
28
NO
6
3- 8
120
28
NO
10
8 - 12
121
28
NO
20
12 - 22
122
28
NO
30
22 - 33
123
28
NO
40
33 - 45
124
28
NO
60
45 - 65
125
28
NO
80
65 - 90
126
28
NO
120
90 - 125
127
28
NO
160
125 - 180
128
28
NC
6
3- 8
129
28
NC
10
8 - 12
130
28
NC
20
12 - 22
131
28
NC
30
22 - 33
132
28
NC
40
33 - 45
133
28
NC
60
45 - 65
134
28
NC
80
65 - 90
135
28
NC
120
90 - 125
136
28
NC
160
125 - 180
