MIL-DTL-12109/13A
REQUIREMENTS:
CABLE M13486/5-1
7.500 ± .250
CONNECTOR
.250
MS27142-2
MAX.
2 SCREWS
5251253
PIN 5351245
.517
.812
TRIGGER PIN
LIFTER
1.594
.562
.350 + .020 (NOTE 3)
.875 DIA
.525 MIN.
BUSHING
1.508
(SOLDER)
1.078
1.84
CORE
4
DRAWING# 6301519
.062
1.219
1.750
PLATE ASS'Y
1.156
6313758
3.219
NOTE: LIFTER
MUST MOVE
1.688
FREELY AFTER
ASSEMBLY
SCREW, LOCKING-MS35265-40
CLAMPING, LOCKING
WASHER-MS27183-7
ASSEMBLY-6301524
1.027 ± .001
HOLE FOR
.513
MANUAL OPERATION
CAP ASSY 6301523,
(TRIGGER ADJUSTMENT)
C
L
2-SCREW-5351254
∅ 1.347 + .005
NOTES:
1. This drawing is for interface and envelope requirements and is not intended to
limit design.
2. Dimensions are inches, Unless otherwise specified, tolerances are ± .010 on
decimals, ± 2° on angular dimensions.
FIGURE 1. Solenoid characteristics.
