AN3372
REVISION 6
Inches
mm
Inches
mm
.010
0.025
.907
2.303
.031
0.079
1.562
3.969
.062
0.158
2.625
6.668
.093
0.238
2.700
6.858
.250
0.635
2.886
7.330
.265
0.673
3.250
8.255
.266
0.675
3.468
8.810
.375
0.952
3.687
9.366
.407
1.034
3.718
9.445
.689
1.750
4.062
10.318
.719
1.826
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.016 (0.040 mm).
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 50,000 minimum.
Contact data:
Contact voltage drop: Not applicable.
Coil temperature rise: Not applicable.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Type of load
Amperes
Resistive (28 Volts DC)
200
Resistive (400 Hz, 115 Volts AC)
150
Inductive (28 Volts DC)
100
Motor (28 Volts DC)
150
Motor (400 Hz, 115 Volts AC)
100
1/ For resistive load tests, one set of contacts shall
be tested with rated resistive DC load and the other
set of contacts shall be tested with rated resistive
AC load.
Overload current: Not applicable.
Rupture current: Not applicable.
2
