AN3324
REVISION 4
Inches
mm
Inches
mm
.005
0.013
.313
0.795
.010
0.025
.375
0.953
.016
0.040
.438
1.113
.031
0.079
.531
1.349
.040
0.102
.548
1.392
.042
0.107
.557
1.415
.062
0.157
.875
2.223
.141
0.358
1.938
4.923
.205
0.521
2.625
6.668
.260
0.660
3.250
8.255
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance are .016 (0.040 mm).
4. Contour shown by phantom lines is optional with the manufacturer provided the maximum dimensions specified
are not exceeded.
5. Terminal post holes shall be counterbored and properly filled with socket compound, or equivalent.
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 25,000 minimum.
Contact data:
Contact voltage drop: Not applicable.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Normally Open
Normally Closed
Type of load
Amperes
Amperes
Resistive (DC)
25
20
Inductive
20
20
Motor
20
10
Overload current: Not applicable.
Rupture current: Not applicable.
