AN3306
REVISION 7
Inches
mm
.016
0.406
1.813
46.050
2.563
65.100
3.563
90.500
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are .016 (0.406 mm).
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 50,000 minimum.
Contact data:
Contact voltage drop:
Initial: 0.150 volt maximum. Applicable only for AN3306-2.
After life: 0.175 maximum. Applicable only for AN3306-2.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Type of load
Amperes
Resistive (DC)
10
Resistive (AC 400 Hz, 115 volts)
10
Inductive
10
Motor
6
Overload current: See MIL-PRF-6106. Not applicable to AN3306-1.
Rupture current: See MIL-PRF-6106. Not applicable AN3306-1.
2
