AN3303
REVISION 3
Inches
mm
.016
0.040
1.375
3.493
1.438
3.651
1.563
3.969
1.657
4.207
1.75
4.445
2.50
6.35
3.50
8.89
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance are �.016 (0.040 mm).
FIGURE 1. Configurations and dimensions - Continued.
REQUIREMENTS
Operating cycles: 50,000 minimum.
Contact data:
Contact voltage drop: Not applicable.
Load ratings: See Table I.
TABLE I - Rated contact load (per pole).
Type of load
Amperes
Resistive (DC)
3
Resistive (AC 400 Hz, 115 volts)
3
Inductive
1.5
Motor
1.5
Overload current: Not applicable.
Rupture current: Not applicable.
2
